22. SETTINGS MENU
22-16
22.13 CCRP
The [CCRP] page provides for selection of CCRP (Consistent Common Reference
Point) and shows the setting of anchor installation position and the location of various
sensors.
No. Name Description
1 CCRP Select the CCRP to use in the case of multiple CCRPs.
2 Anchor Enter anchor installation position (X and Y values from
CCRP). The setting ranges are X, -15.0 to 15 m; Y, 0.0 to
300.0 m.
3 Display Filter Check the items to show on the ship’s graphic.
4 Ship’s graphic Shows the location of the sensors selected at the [Dis-
play Filter].
