Husky Altanium Matrix5 User Manual

Data Collection Start Conditions 169
User Guide v 1.0 — February 2020 Data Recording
4. Select a start signal.
5. Touch the Heats Running check box, so the check mark shows, if applicable.
6. Touch the servo control system Engaged check box, so the check mark shows, if
applicable.
For example, if UltraSync-E is installed on your system, it will show as UltraSync-E
Engaged.
12.4.3.1 Data Collection Start Conditions
Table 12-4 shows the data collection start conditions with specified operations enabled and
disabled.
12.4.3.2 Data Collection Stop Conditions
Table 12-5 shows the data collection stop conditions with specified operations enabled and
disabled
Table 12-4 Cycle Mode - Conditions to Start (UltraSync-E or Altanium Servo Control Installed)
Heats
Running
Condition
Enabled
UltraSync-E
Engaged
Condition
Enabled
Mold Servo
Controller
Engaged
Condition
Enabled
Cycle Mode
Conditions
Selection
Shown on
Screen
Conditions to Start
Yes Yes No Yes Start signal goes High AND heats are
turned On and At Temperature AND
UltraSync-E is engaged
Yes No Yes Yes Start signal goes high AND heats are
turned on and At Temperature AND
Mold Servo Controller is engaged
Yes Yes Yes Yes Start signal goes high AND heats are
turned on and are At Temperature
AND UltraSync-E is engaged AND
Mold Servo Controller is engaged
No Yes No No Start signal goes high AND UltraSync-E
is engaged
No No Yes No Start signal goes high AND mold servo
controller is engaged
No Yes Yes Yes Start signal goes high AND UltraSync-E
is engaged AND Mold Servo Controller
is engaged
Yes No No Yes Not permitted
