192 Controller Status
14.1.8 Controller Status
Summary This command is used to read the condition of a single zone. The
definition of the status bits is given below:
BIT SPI DEFINITION SYSTEM DEFINITION
0 Heater Power Power to heater is not zero
1 Soft Start Soft start is active
2 Manual Control Manual regulation (Not Auto
or View)
3 Low Alarm 1 Alarm under temperature
4 High Alarm 1 Alarm over temperature
5 Low Alarm 2 Abort under temperature
6 High Alarm 2 Abort over temperature
7 Open T/C Alarm Lost thermocouple
8 Reverse T/C Alarm Reversed thermocouple
9 Shorted T/C Alarm Not supported
10 Open Output Device Fuse blown
11 Shorted Output Not supported
12 Ground Fault Not supported
13 Low Current Alarm Not supported
14 High current Not supported
15 Out Of Control Not supported
Errors An invalid zone number condition will give an invalid data error in
response to a polled function.
