Husky Altanium Matrix5 User Manual

Part Count Base Connector ID 187
User Guide v 1.0 — February 2020 System Options
13.3.3 Part Count Base Connector ID
The part count base connector pins are identified in Table 13-9.
13.3.4 Remote Load Base Connector ID
The remote load base connector pins are identified in Table 13-10.
Output / R GRN/WHT Communications error
Output / S BLK/RED/WHT Communications error
Output / T BLK/RED Mold cooling enable
Output / U RED/BLK Mold cooling enable
Output / V RED/WHT Process outside limit
Output / W WHT/RED Process outside limit
Output / X GRN/BLK Boost Active
Output / Y GRN/BLK/WHT Boost Active
Output / Z WHT/RED/BLK “Run light”
Output / a RED/BLK/WHT “Run light”
Table 13-8 Output Base Connector Pins (Continued)
Connector/Pin Field Cable Wire Color Signal Function
Table 13-9 Part Count Base Connector Pins
Connector/Pin Field Cable Wire Color Signal Function
Part Count / A BLK Reset parts counter
Part Count / B WHT Count Parts
Part Count / C RED 12 V+
Part Count / D GRN 0 V
Part Count / E BRN Sack full
Part Count / F BLU Sack full
Table 13-10 Remote Load Base Connector Pins
Connector/Pin Field Cable Wire Color Signal Function
Remote Load / A WHT Load setup
Remote Load / B WHT/BLK Setup B0
Remote Load / C BLK Setup B1
