4.1.9 Common Buttons
The Common area of the Altanium Home screen gives access to the screens used for the
alarms, event history, and process monitoring. Table 4-11 gives a description for each of the
related screens for the Common buttons.
Touch the Supply Voltage button to see a graphical view of the phase
pairs by the Supply Configuration parameter selected in the System
Setup screen. Refer to Section 10.25 for information.
Touch the Energy Display button to see the system real-time energy
accumulation data. Refer to Section 10.15 for information.
Table 4-10 Temperature Control Buttons (Continued)
View Button Description
Table 4-11 Common Buttons
Screen Description
Common Screens
Touch the Alarms button to see the list of alarms that have occurred.
Refer to Section 9.4 for information.
Touch the Event History button to see a list of the operations done at
the Altanium screen. Refer to Section 9.5 for information.
Touch the Process Monitoring button to access the screens for
graphical trend and history plots, enter zone target settings, and other
specifications. Refer to Chapter 12 for information.
