186 Output Base Connector ID
13.3.2 Output Base Connector ID
The maximum loads on the digital outputs are as follows:
• 110 VDC / 0.3 A - 33 W
• 30 VDC / 2.0 A - 60 W
• 120 VAC / 0.5 A - 60 VA
• 240 VAC / 0.25 A - 60 VA
The output connector pins are identified in Table 13-8.
Input / E BLU Manual boost
Input / F BLU/WHT Remote Stop
Input / G BLU/BLK 12 V+
Input / H GRN 12 V+
Input / J GRN/BLK 0 V
Input / K GRN/WHT 0 V
Input / L ORG Cycle Input
Table 13-7 Input Base Connector Pins (Continued)
Connector/Pin Field Cable Wire Color Signal Function
Table 13-8 Output Base Connector Pins
Connector/Pin Field Cable Wire Color Signal Function
Output / A GRN Alarm
Output / B ORG/GRN Alarm
Output / C RED Abort (PCM)
Output / D BLU/RED Abort (PCM)
Output / E ORG At temperature
Output / F ORG/BLK At temperature
Output / G BLK Remote standby
Output / H BLU/BLK Remote standby
Output / J WHT At boost temperature
Output / K BLU/WHT At boost temperature
Output / L RED/GRN At standby temperature
Output / M ORG/RED At standby temperature
Output / N BLK/WHT Maximum temperature error
Output / P WHT/BLK Maximum temperature error
