Grove Published 7-23-2020, Control # 668-02 3-33
GRT9165 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
3
OPTIONAL SINGLE AXIS CONTROLLERS
The following single axis controllers (Figure 3-25) are
available as an option on the GRT9165 crane.
FIGURE 3-25
Item Description Page
1 Swing Controller 3-34
2 Auxiliary Hoist Controller 3-34
3
Boom Lift – Telescope – Luffing
Jib
Boom Extension Controller
3-34
4 Main Hoist Controller 3-34
5 Hoist Rotation Indicators (Not Shown) 3-34
9838-28
4
3
2
1
5
5
