Grove Published 7-23-2020, Control # 668-02 4-81
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
Crane Information Area
The following indicators make up the Crane Information Area
(Figure 4-77) of the ODM Main Screen.
FIGURE 4-77
1 3
7
8 96
9902-1
42 5
Item Description Item Description
1 Direction/Gear Indicator 6 Transmission Oil Temperature Indicator
2 Engine Speed Indicator 7 Speedometer (Optional)
3 Engine Coolant Temperature Indicator 8 Battery/Charging Voltage Indicator
4 Diesel Exhaust Fluid (DEF) Level Indicator 9 Hydraulic Oil Temperature Indicator
5 Diesel Fuel Level Indicator
