Manitowoc Grove GRT9165 User Manual

MAINTENANCE AND LUBRICATION GRT9165 OPERATOR MANUAL
6-32 Published 7-23-2020, Control # 668-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Outrigger Lubrication
33
Jack Cylinder
Support Tubes
Figure 6-16 L
Brush on I.D.
of each
cylinder
support tube
and wear
bands
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON I.D. of
4 service points
See NOTE 37.
See NOTE 38.
See NOTE 42.
34
Outrigger Box
Pins
See NOTE 42.
Figure 6-16 L Brush on
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON
8 service points at
assembly and/or
tear down.
See NOTE 37.
35
Outrigger Beams
–Top Plates
Figure 6-16 L Brush on
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON beam
top plate as beam
is fully extended.
See NOTE 37.
See NOTE 39.
See NOTE 40.
See NOTE 41.
See NOTE 42.
Outrigger Beams
–Bump-outs
Figure 6-16 L Brush on
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON 3 TOP,
and 3 BOTTOM
bump-outs on each
side of outrigger
beam
12 service points
each beam.
See NOTE 37.
See NOTE 39.
See NOTE 40.
See NOTE 41.
See NOTE 42.
36 Wear Pads Figure 6-16 L Brush on
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON
2 TOP wear pads
(rectangular–rear),
and 2 BOTTOM
wear pads
(circular–front) of ea
outrigger beam
4 service points
each beam
See NOTE 37.
See NOTE 39.
See NOTE 42.
37
Jack Cylinder
Barrels
See NOTE 42.
Figure 6-16 L Brush on
Every 50 hours, or
1 week of service,
whichever interval
comes first
BRUSH ON
4 service points
See NOTE 37.
See NOTE 38.
