GRT9165 OPERATOR MANUAL SET-UP AND INSTALLATION
Stowing an Outrigger Float for Transport
NOTE: An outrigger float weighs approximately 30 kg
(65.0 lbs).
1. Remove pins (3) from stowage posts (2).
2. Lift outrigger float into position using handles (4).
3. Install outrigger float (1) on stowage posts (2) on the
outrigger box.
4. Install pins (3) in posts (2) to secure the outrigger float.
Removing an Outrigger Float from Stowage
NOTE: An outrigger float weighs approximately 30 kg
(65.0 lbs).
1. Hold the handle (4) and remove pins (3) from posts (2).
2. Remove the outrigger float (1) from stowage posts (2) on
the outrigger box.
3. Install pins (3) in stowage posts (2).
Hydraulic Hose Drum (Optional)
If installed on the boom, the hydraulic hose drum must be
secured before transport. For more information, see
Checking the Locking Device on the Hose Drum, page 5-73.
Boom Position Indicator Light and
Anemometer (Optional)
The boom position light and anemometer assembly must be
removed and stowed for transport. For more information, see
Anemometer/Boom Position Light (Optional), page 5-88.
Auxiliary Single-Sheave Boom Nose
The auxiliary single-sheave boom nose must be secured for
transport. For more information, see Rigging the Auxiliary
Single-Sheave Boom Nose for Transport, page 5-87.
Boom Lift Cylinder
If the boom is removed for transport, properly secure the lift
cylinder. For information about removing the boom, see the
Service Manual.
INSTALLING CABLE ON THE HOIST
Refer to Figure 5-11.
NOTE: Straighten cable before installing on hoist drum.
1. Place cable (1) over boom nose sheave and route to
hoist drum (2).
2. Rotate hoist drum so cable slot located on left side of
drum is easily accessible.
3. Insert cable through slot (3) and wedge block (4). Loop
around anchor wedge (6) and route back through wedge
block to clamp (5). Ensure the cable is routed over the
guide inside of drum. End of cable should extend
approximately 50 mm (2 in) beyond clamp. Tighten
clamp.
4. Adjust cable so clamp side is snug against guide.
Position anchor wedge in wedge block. Pull firmly on
inside hoist side of cable to secure the wedge.
5. If wedge does not seat securely in slot, carefully tap
cable and top of wedge (7) with a mallet.
DANGER
Do not use platform for hauling passengers. Death or
serious injury could occur.
No storage of components is allowed on the platform.
Only one person at a time is allowed on the platform.
CAUTION
If cable is wound from storage drum, rotate reel in same
direction as hoist.
