Manitowoc Grove GRT9165 User Manual

Grove Published 7-23-2020, Control # 668-02 4-25
GRT9165 OPERATOR MANUAL OPERATING PROCEDURES
4
Dual Axis Controllers
1. Press the Swing Enable/Disable Switch on left armrest
to enable the swing function.
The Swing Enable Indicator in the Status Bar area
(Figure 4-80) of the Operator Display Module (ODM) will
come on (green).
2. Push controller on left armrest to the right and hold to
swing right (rotates turntable clockwise) or push
controller to the left and hold to swing left (rotates
turntable counterclockwise).
3. To stop swinging, let swing controller return to the center
(neutral) position and apply the swing brake with the
Swing Brake Pedal (refer to Swing Brake Pedal, page
3-36).
Single Axis Controller (Optional)
1. Press the Swing Enable/Disable Switch on left armrest
to enable the swing function.
The Swing Enable Indicator will come on (green).
2. Push outer controller on left armrest forward and hold to
swing right (rotates turntable clockwise) or pull controller
rearward and hold to swing left (rotates turntable
counterclockwise).
3. To stop swinging, let swing controller return to the center
(neutral) position and apply the swing brake with the
Swing Brake Pedal.
Raising and Lowering the Boom
Raising the Boom
Dual Axis Controllers
1. Press the Boom Lift Enable/Disable Switch on right
armrest to enable the boom lift function.
The Boom Lift Enable Indicator in the Status Bar area
(Figure 4-80) of the Operator Display Module (ODM) will
come on (green).
2. Push controller on right armrest to the left and hold to
raise the boom.
3. When boom angle gets to the desired elevation, let
controller return to the center (neutral) position to stop
boom lift function.
Single Axis Controller (Optional)
1. Press the Boom Lift Enable/Disable Switch on right
armrest to enable the boom lift function.
The Boom Lift Enable Indicator will come on (green).
2. Pull inner controller on right armrest rearward and hold
to raise the boom.
3. When boom angle gets to the desired elevation, let
controller return to the center (neutral) position to stop
boom lift function.
DANGER
Crushing Hazard!
Keep area above and below boom clear of all obstructions
and personnel when elevating the boom.
