OPERATING CONTROLS AND FEATURES GRT9165 OPERATOR MANUAL
3-54 Published 7-23-2020, Control # 668-02
Cab-Mounted Working Lights
Adjustable Cab-Mounted Working Lights (1, Figure 3-42) are
located on the front of the cab.
The lights are controlled by the Cab-Mounted Lights Switch,
page 3-11.
Motorized Boom-Mounted Working Lights
Motorized Boom-Mounted Working Lights (1, Figure 3-43)
are optional crane equipment that are mounted to the bottom
of the boom base section.
The working lights are controlled by the Boom-Mounted
Lights Switch (Optional), page 3-11.
The working lights are adjusted by the Boom-Mounted Lights
Motor Switch (Optional), page 3-11.
Ladders and Grab Handles
Ladders (1, Figure 3-44 to Figure 3-47) and grab handles (2)
are located at the left and right sides of the crane as well as
at the front and rear of the crane.
Use these ladders and grab handles to climb and access the
carrier deck or the cab.
Always maintain a three-point contact to the crane when
using the ladders and grab handles.
FIGURE 3-42
1
9838-19
FIGURE 3-43
9838-23
1
FIGURE 3-44
9838-22
2
2
2
1
LEFT SIDE
