MAINTENANCE AND LUBRICATION GRT9165 OPERATOR MANUAL
6-30 Published 7-23-2020, Control # 668-02
Item
Lube Point
Description
Figure No.
Approved
Lubricant
Approximate
Capacity
Service Interval
Service
Application
Superstructure and Cab Tilt Lubrication
27
Pillow Block
Bearings
See NOTE 34.
Figure 6-14 A
Until grease
extrudes from
entire bearing
circumference
Every 500 hours, or
3 months of service,
whichever interval
comes first
LUBRICATE
2 grease fittings per
pillow block bearing,
2 bearings
4 service points
See NOTE 31.
See NOTE 33.
28
Turntable Swivel
Lock Pin
Figure 6-14 G Spray on
Every 500 hours, or
6 months of service,
whichever interval
comes first
SPRAY ON
1 service point
29
Swing Angle
Sensor
Figure 6-14 A
Apply grease
to fitting
See NOTE 32
Every 5000 hours,
or 60 months of
service, whichever
interval comes first
REMOVE M16x1.5
plug from housing
LUBRICATE fitting
on bottom of swing
angle sensor
See NOTE 32.
See NOTE 33.
INSTALL
M16x1.5 plug
TORQUE plug to
25 N·m (18.45 lbf-ft)
30
Cab Tilt Cylinder
Pivot Pins
Figure 6-14 A
Until grease
extrudes
Every 500 hours, or
3 months of service,
whichever interval
comes first
LUBRICATE
2 service points
See NOTE 31.
See NOTE 33.
See NOTE 35.
31
Cab Door Tracks
and Rollers
Figure 6-15 Light Oil — Every 6 months
LUBRICATE
2 service points
See NOTE 36.
32
Air Conditioner
Condenser Filter
Figure 6-15 — —
Every 1000 hours, or
6 months of service,
whichever interval
comes first
CHECK/CLEAN
air conditioner
condenser filter
1 service point
NOTE 31: Use grease fittings provided.
NOTE 32: Remove plug (M16x1.5) from housing. Apply grease to fitting on bottom of sensor. Install plug again and torque
plug to 25 N·m (18.45 lbf-ft).
NOTE 33: Before operating crane in cold weather (arctic) ambient temperatures below -9°C (+15°F), Standard bearing
grease must be fully purged and replaced with Cold Weather grease meeting Grove U.S. L.L.C. specifications
as shown in Table 6-4: Approved Lubricant Reference Table, page 6-11 in this Operator Manual. See also your
GRT9165 Service Manual for maintenance and lubrication instructions.
NOTE 34: Perform same service for each of two (2) Pillow Block Bearings.
NOTE 35: Perform lubrication service for each grease fitting on two (2) Cab Tilt Cylinder Pivot Pins.
NOTE 36: Perform lubrication service for each of two (2) Cab Door Tracks and Rollers.
