User Instructions Section 5847
Spec. Nos. 586505000 and 5865055000 (Model LMS1000) Issue AL, July 24, 2006
Chapter 2. Operating LMS1000 Page 2-33
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
ACCESSING A VORTEX POWER SYSTEM (VPS)
If LMS1000 is connected to a VPS, the VPS can be accessed by issuing certain
LMS1000 commands. Commands available can be viewed by entering the LMS1000
command HELP VORTEX.
Note: The VPS contains an MCA remote lockout feature which disables changing VPS
adjustment/configuration/calibration settings via LMS1000.
Note: Only one LMS1000 user is allowed to change VPS settings at a time. LMS1000
locks out any other user attempting to change VPS settings.
Password:
When LMS1000 is initially powered up or during a reset, LMS1000
automatically issues a password to gain remote access to the VPS. A newly installed
LMS1000 issues the VPS's default remote access password (VORTEX, in all capitol
letters). If the VPS's remote access password has been changed from its default, the
password issued by LMS1000 must also be changed. See command SET VORTEX
PASSWORD. You must know the existing password set in LMS1000 to change it. If
LMS1000 does not successfully connect with the VPS during power up or reset, a
message is displayed when a user attempts VPS access.
If the password is changed in LMS1000, record the new password in a secure place.
There is no way to view the password set in LMS1000.
Also, if the VPS MCA's remote access password is ever changed, record the new
password in a secure place. The current VPS MCA remote access password cannot be
viewed remotely from LMS1000. The password can be viewed locally, from the VPS
MCA's Interface Pad. Refer to the VPS manual for a procedure.
LMS1000 Event Log:
Certain actions performed at the VPS's MCA local interface pad
and via LMS1000 are recorded in the LMS1000 event log. Refer to "Viewing and
Clearing the Event Log" in this chapter for a listing of recorded VPS events.
LMS1000 Alarm Log:
Refer to "Viewing and Clearing the Alarm Log" in this chapter for
a list of VPS alarms that are recorded in the Alarm Log.
Note: Binary Channel B0085 monitors the communications link between the LMS1000
and Vortex Power System. This channel alarms if this communications link is not
operational. A failed communications link generates an Alarm Log entry and an
Event Log entry.
LMS1000 Commands:
The Vortex Interface provides analog channels A9001-A9081
and binary channels B9001-B9080. These channels are dedicated to monitor
predetermined VPS parameters. The function of these channels are preset and cannot
be changed. To efficiently use these channels with traditional (non-Vortex specific)
commands, refer to Table 2-1 which shows the mapping of VPS parameters to these
dedicated channels.
