User Instructions Section 5847
Spec. Nos. 586505000 and 5865055000 (Model LMS1000) Issue AL, July 24, 2006
Chapter 2. Operating LMS1000 Page 2-61
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
USING THE AC ANALYZER INTERFACE
(WHEN 586505000/586505500 LIST 85 INSTALLED)
Refer to the documentation furnished with the AC Analyzer. LMS AC Analyzer Interface
is 9600, n, 8, 1. Set the AC Analyzer to 9600, n, 8, 1 as node #1.
The following LMS analog and binary channels are added.
Channel
Number
Channel Name
A7101 Phase 1 Voltage (VAC)
A7102 Phase 2 Voltage (VAC)
A7103 Phase 3 Voltage (VAC)
A7104 Phase 1-2 Voltage (VAC)
A7105 Phase 2-3 Voltage (VAC)
A7106 Phase 1-3 Voltage (VAC)
A7107 Phase 1 Current (AMPS)
A7108 Phase 2 Current (AMPS)
A7109 Phase 3 Current (AMPS)
A7110 Phase 1 Power Factor
A7111 Phase 2 Power Factor
A7112 Phase 3 Power Factor
A7113 Phase 1 Apparent Power (VA)
A7114 Phase 2 Apparent Power (VA)
A7115 Phase 3 Apparent Power (VA)
A7116 Phase 1 Real Power (W)
A7117 Phase 2 Real Power (W)
A7118 Phase 3 Real Power (W)
A7119 Phase 1 Reactive Power (VAR)
A7120 Phase 2 Reactive Power (VAR)
A7121 Phase 3 Reactive Power (VAR)
A7122 Average Voltage (VAC)
A7123 Average Current (AMPS)
A7124 Average Power Factor
A7125 Average Apparent Power (VA)
A7126 Average Real Power (W)
A7127 Average Reactive Power (VAR)
A7128 Frequency (HZ)
A7129 Real Energy (WH)
A7130 Reactive Energy (VARH)
A7131 Average Real Pwr., 15m (W)
A7132 Average Reactive Pwr., 15m (VAR)
B7101 AC Analyzer Com. Failure
