Emerson LMS1000 User Manual

Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-48 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Typical Screen Display
Command<4>: CLR POWER
Power Stats cleared.
Command<4>: CLR POWER 1
Power Stats cleared.
Determining if the Power Metering Option is Installed
Enter the command OPTIONS. In the displayed information, look for “Power Metering”
under the column heading “Option Name”. Look for “installed, enabled” under the
“Status” column heading.
If the Power Metering option’s status is listed as “not installed”, contact Emerson Network
Power and tell them you would like the Power Metering option installed on your
LMS1000.
What Do I Need, How Do I Order?
Foremost you’ll need to specify the Power Metering option. Specify
586505000/586505500 List 87. Note that this option must be factory installed, or field
installed by Emerson Network Power only. Note this option can be field installed
remotely via dial-up phone lines if your LMS1000 is equipped with a modem or via
Ethernet if connected to a TCP/IP network.
Second, you need at least one analog circuit card. Specify 586505000/586505500 List
20 (this gives you analog circuit card Part No. 506336). This analog circuit card provides
4 analog inputs. One will be connected to system voltage. This leaves three for
measuring customer loads.
Order one additional analog circuit card per four additional customer loads to be
monitored. Note that there is also an 8-input analog circuit card (586505000/586505500
List 22) available which monitors up to eight 50 mv shunts.
Also order one (1) in-line fuse kit to protect the analog leads connected to system
voltage. Specify 586505000/586505500 List BE (3/8” ring lug) or List BF (5/16” ring lug).
And order a current limit resistor kit for each customer load to be monitored for power
consumption. Specify 586505000/586505500 List BA (3/8” ring lug), List BB (splice), or
List BC (ring lug for #10 stud).
