Emerson LMS1000 User Manual

Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-44 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Setting LPS Current Limit: Use the command SET LPS SYSTEM CURLIMIT. This
command is available to a user with access to level 6 commands.
Setting LPS Alarm Parameters:
Use the commands SET LPS SYSTEM HIVLTALM1,
SET LPS SYSTEM HIVLTALM2, SET LPS SYSTEM BATONDISCH, SET LPS SYSTEM
VERYLOWVOLT, SET LPS SYSTEM LOADCURRENT, SET LPS SYSTEM
LOADACURRENT, SET LPS SYSTEM LOADBCURRENT, SET LPS SYSTEM
HI1TEMPALM, SET LPS SYSTEM HI2TEMPALM, SET LPS SYSTEM LOW1TEMPALM,
and SET LPS SYSTEM LOW2TEMPALM. These commands are available to a user with
access to level 5 commands.
Setting LPS MCA "CAN I/O" Circuit Card Parameters:
Use the commands SET LPS
CANIO and SET LPS MESSAGES CANIO_BD. These commands are available to a
user with access to level 6 commands.
VIEWING SOFTWARE OPTIONS INSTALLED
Enter the OPTIONS command. A list of all available options is displayed. In the list,
options that are currently installed are indicated along with, if appropriate, the port
assigned to the option.
