Section 5847 User Instructions
Issue AL, July 24, 2006 Spec. Nos. 586505000 and 5865055000 (Model LMS1000)
Page 2-46 Chapter 2. Operating LMS1000
This document is property of Emerson Network Power, Energy Systems, North America, Inc. and contains confidential and proprietary information owned by Emerson Network Power, Energy
Systems, North America, Inc. Any copying, use, or disclosure of it without the written permission of Emerson Network Power, Energy Systems, North America, Inc. is strictly prohibited.
Using Power Metering
To display a power consumption report, enter the command POWER. The POWER
command is available to a user programmed for access to level 1 commands. The
command is also described in "Chapter 3. Commands".
For the “comma separated value” format, enter the command POWER CSV.
To clear the Power Metering data, enter the command CLR POWER. But be careful,
entering this command destroys all previously saved data. The CLR POWER command
is available to a user programmed for access to level 4 commands. The command is
also described in "Chapter 3. Commands".
POWER Command
This command displays power consumption data for function channels configured to
calculate power, and is available for all users (command level 1).
Command syntax is POWER, POW, POWER CSV, or POW CSV.
A power consumption report is generated and displayed for all function channels
configured with the UNIT TEXT of KW, and the appropriate program line to generate
power consumption values. Power consumption data consists of power consumed for
current day, current week, and current month. In addition, power consumption data for
the previous day, previous week, and previous month is also displayed.
Entering the command modifier CSV displays the power consumption report in the
“comma separated value” format. This allows the data to be imported into a spreadsheet.
Typical Screen Display
Command<1>: POWER
POWER CONSUMPTION STATISTICS AS OF 13:04:45 ON 04/29/99
F0001 POWER STATS: CUSTOMER BILL LOADA POWER
Daily
04/28/99: 55.07 KWH
04/29/99: 29.80 KWH
Weekly
04/19/99 THROUGH 04/25/99: 384.8 KWH
04/26/99 THROUGH 04/29/99: 194.9 KWH
Monthly
03/14/99 THROUGH 03/31/99: 887.9 KWH
04/01/99 THROUGH 04/29/99: 1505.0 KWH
F0002 POWER STATS: CUSTOMER BILL LOADB POWER
Daily
04/28/99: 109.20 KWH
04/29/99: 59.17 KWH
To Next Page
