11.4.1.2 Configuration Procedure
Figure 11-11 shows the configuration procedure for a fiber to the building (FTTB) or fiber to
the curb (FTTC) Ethernet cascading network where an optical network unit (ONU) works as an
independent NE.
Figure 11-11 Configuration process for an FTTB or FTTC Ethernet cascading network where
an ONU works as an independent NE
The following table describes the configuration steps.
Configur
ation
Object
Step Description
Optical
line
terminal
(OLT)
Configure the
working mode of an
Ethernet cascading
board.
An Ethernet cascading board supports various working
modes. Configure the working mode to cascade in this
scenario.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1024
