Item Data
Uplink ports Forwarding Dynamic Host Configuration Protocol (DHCP),
broadband, and VoIP packets: 0/4/0
Forwarding cable modem (CM) management, VoD, and multicast
packets: 0/5/0
Procedure
Step 1 Create an S-VLAN.
The S-VLAN is a user-side service VLAN between the optical line terminal (OLT) and the D-
CMTS. The OLT works in Layer 3 forwarding mode.
huawei(config)#vlan 100 smart
Step 2 Create a CM S-VLAN.
The CM S-VLAN identifies a CM service flow. After the CM S-VLAN is configured, the OLT
automatically creates a CM service flow when the CM goes online.
NOTE
l The cable service-vlan vlanid command is used to configure a global S-VLAN for CM services. After the
configuration, all CM services of the D-CMTSs connected to the same OLT use the same VLAN. When the
number of IP address segments planned for an OLT is less than eight, this command is recommended.
l The cable service-vlan vlanid frameid/slotid command is used to configure an S-VLAN for CM services
on a specified D-CMTS. After the configuration, the D-CMTS does not use the global S-VLAN. When the
number of IP address segments planned for an OLT is greater than eight, this command is recommended.
huawei(config)#cable service-vlan 100
Info: The new service VLAN will take effect after the CM is restarted, are you
sure to modify? (y/n)[n]:y
----End
15.4.1.11 Configuring the EQAM VoD Service
If the MA5633 is equipped with a built-in EQAM module, the MA5633 sets idle downstream
DOCSIS channels as EQAM channels to transmit VoD data.
Prerequisites
The MA5633 supports built-in EQAM.
Context
In multiservice operator (MSO)-oriented solutions, both HFC networks and STBs use the
broadcast television QAM technology and support only RF signals.
Video data is encapsulated into IP and UDP packet headers that are transmitted on IP networks,
which cannot be transmitted on HFC networks. To transmit the video data on HFC networks,
the video data must be modulated into RF signals using the EQAM module.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1613
