Item Data Description
Policy for controlling
frequent online and
offline on ports
no-limit -
Vectoring group Group ID: 1 All ports are added to the default
vectoring group 1.
Vectoring profile Profile ID: 1 The upstream/
downstream crosstalk
cancelation function in default
Profile 1 are as follows:
l Upstream crosstalk
cancelation: enable
l Downstream crosstalk
cancelation: enable
-
Procedure
Step 1 Globally configure the band plan type.
huawei(config)#xdsl vectoring bandplan-type 998ade us0-type type-a
Step 2 Configure the vectoring profile as huawei and bind it to the VDSL2 port in the vectoring group.
huawei(config)#xdsl vectoring-profile add control enable enable name huawei
huawei(config)#interface vdsl 1/1
huawei(config-if-vdsl-1/1)#vectoring-config all profile-name huawei
huawei(config-if-vdsl-1/1)#quit
Step 3 Configure the policy for activating a vectoring legacy CPE.
huawei(config)#xdsl vectoring legacy-cpe activate-policy no-limit
Step 4 Configure the policy for controlling frequent online and offline on ports.
huawei(config)#xdsl frequent-retrain-control 1/1/0 control-policy no-limit
Step 5 Enable the global vectoring.
huawei(config)#xdsl vectoring enable
Step 6 Save the data.
huawei(config)#save
----End
11.4.2.8 Configuring Link Aggregation, Congestion Control, and Security Policies
This topic describes how to configure uplink aggregation and priority scheduling policies for
upstream queues in global config mode to enhance service reliability, and configure security
policies in global config mode to secure services.
Context
Link aggregation aggregates multiple upstream Ethernet ports into a group to increase the uplink
bandwidth and improve service reliability. It is advisable to configure congestion control.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1059
