l The subscriber can watch program 1 on the TV.
9.8 P2P Access: Configuring FTTH Service
Users connected to the OLT through an ONT, and are therefore provided with the Internet, VoIP,
and IPTV service through a same port.
Service Requirements
l ONT_1 and ONT_2 are provided with the triple play service through FTTH.
l The Internet access service is provided in the PPPoE access mode.
l The IPTV user connected to ONT_1 can watch all the programs, and the IPTV user
connected to ONT_2 can watch only program BTV-1.
l The VoIP service and the IPTV service are provided in the DHCP mode and obtain IP
addresses from the DHCP server in the DHCP option-60 mode.
l After receiving different traffic streams, the OLT provides different QoS guarantees to the
traffic streams according to the priorities of the traffic streams.
l Traffic streams are differentiated on the OLT by the user-side VLAN (C-VLAN).
Figure 9-8 Example network of the optical fiber access service in the single-port for multiple
services mode
Table 9-7 Data plan for configuring the VLANs
Configuration Item Data Item Data
SVLAN HSI service SVLAN: 100
CVLAN: 2
IPTV service SVLAN: 1000
CVLAN: 4
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
717
