16.4.1.8 Configuring a Management Channel Between an OLT and a D-CMTS
This section describes how to configure a management channel between an optical line terminal
(OLT) and a distributed cable modem termination system (D-CMTS). After the configuration,
you can log in to the D-CMTS from the OLT and configure the D-CMTS.
Data Plan
Item Data Remarks
Management VLAN
and IP address of the
OLT
ID of the management
VLAN: 8
Type of the management
VLAN: smart
Management IP address:
192.168.50.1/24
To remotely log in to the D-CMTS
from the OLT for configuration, ensure
that the management VLAN of the
OLT is the same as that of the D-CMTS
and that the management IP address of
the OLT is in the same network
segment as that of the D-CMTS.
Management VLAN
and IP address of the
D-CMTS
ID of the management
VLAN: 8
Type of the management
VLAN: smart
Management IP address:
192.168.50.2/24
Procedure
Step 1 Configure a management channel between the OLT and the D-CMTS.
NOTE
Perform this operation only when the OLT remotely manages the D-CMTS through SNMP.
1. Set the inband management VLAN and IP address of the OLT.
To remotely log in to the D-CMTS for configuration, set the inband management VLANs
and IP addresses of the OLT and the D-CMTS on the OLT.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/5 0
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.1 24
huawei(config-if-vlanif8)#quit
2. Set the inband management VLAN and IP address of the D-CMTS.
Set the static IP address of the D-CMTS to 192.168.50.2/24, the IP address of the gateway
to 192.168.50.1, and the ID of the management VLAN to 8 (the same as the management
VLAN of the OLT).
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont ipconfig 1 1 static ip-address 192.168.50.2
mask 255.255.255.0 gateway
192.168.50.1 vlan 8
huawei(config-if-gpon-0/3)#quit
3. Configure an inband management service flow.
The following configurations are used as an example to configure an inband management
service flow:
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1750
