11.2.2 Principle of QoS Data Plan
The QoS plan for FTTB is an E2E planning, and it can be divided into following policies: traffic
classification, marking, scheduling, traffic monitoring, and DBA policies.
Traffic Classification, Marking, and Scheduling Policies
Service
Type
802.1p
Priority
Queue
Scheduling
Method
OLT
Queue ID
(8 Queues)
ONT Queue.ID
Supporting
Eight
Queues
Supporting
Four
Queues
Management
service
6 PQ 6 6 3
VoIP service 5 PQ 5 5 2
IPTV service 4 PQ 4 4 2
Internet
access
service
0 PQ 0 0 0
Note
l Different service packets are distinguished by different VLAN IDs. GEM ports are mapped
based on 802.1p priorities for the GPON system.
l Service priorities in this table are recommended values. The service priorities are arranged
according to the operators's actual planning.
Traffic Monitoring and DBA Policies
Items Management
service
Internet
access service
VoIP service IPTV service
GEM port 11 [Remark 1] 12 13 14
TCONT All services share a T-CONT.
DBA type Type 3 (DBA profile: assured bandwidth + maximum bandwidth. Users
are allowed to preempt the bandwidth on condition that the users' assured
bandwidth is guaranteed. However, the total bandwidth cannot exceed the
maximum bandwidth.)
DBA bandwidth
planning
Configure the DBA bandwidth according to the user's bandwidth package.
The assured bandwidth is the maximum bandwidth required by
management packets, VoIP, and IPTV upstream packets. The maximum
bandwidth is larger than or equal to the maximum bandwidth that users
apply.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
835
