address of the gateway for the STB domain to 10.200.160.1.
huawei(config-if-vlanif100)#quit
----End
16.4.1.4 Configuring a Route
This section describes how to implement network communication by configuring a route in
Layer 3 networking with an optical line terminal (OLT). Through the route, packets are
forwarded at Layer 3 between the OLT and its upper-layer devices or servers.
Prerequisites
The upper-layer router has been configured.
Data Plan
Table 16-25 Data plan for the Layer 3 interfaces on the network side
Item IP Address
Layer 3 interfaces on the
OLT network side
Forwarding Dynamic Host Configuration Protocol (DHCP) and
broadband packets:
l VLAN ID: 2004
l Port number: 0/4/0
l IP address: 11.11.11.10/24
Forwarding cable modem (CM) management, VoD, COPS, and
multicast packets:
l VLAN ID: 2005
l Port number: 0/5/0
l IP address: 11.11.12.10/24
Layer 3 interfaces
connecting the router to
the OLT
l Forwarding DHCP and broadband packets: 11.11.11.11
l Forwarding CM management, VoD, COPS, and multicast
packets: 11.11.12.11
l COPS gateway IP address: 192.168.60.1
Upper-layer servers of
the OLT
l DHCP servers:
– DHCP server assigning IP addresses to CMs and media
terminal adapters (MTAs): 192.168.10.10-192.168.10.11
– DHCP server assigning IP addresses to PCs and set top
boxes (STBs): 192.168.10.12-192.168.10.13
l CM management system, VoD server, and multicast server:
192.168.20.10-192.168.20.12
l Softswitch or IP multimedia subsystem (IMS) server:
192.168.50.10
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1739
