l If Run state is offline, a physical line may be broken or the optical module may be damaged.
Check the line and the optical module.
l If Config state is failed, the configured ONU capability exceeds the actual ONU capability.
In this case, run the display ont failed-configuration command in the diagnose mode to
check the failed configuration item and the failure cause. Then, rectify the fault accordingly.
l If the ONU does not match, that is, Match state is mismatch, the port types and number of
ports undermatch the actual port types and number of ports supported by the ONU. In this
case, run the display ont capability command to query the actual capability of the ONU,
and then select one of the following modes to modify the ONU configuration:
– Create a proper ONU profile according to the actual capability of the ONU, and then run
the ont modify command to modify the configuration data of the ONU.
– Modify the ONU profile according to the actual capability of the ONU and save the
modification. Then, the ONU automatically recovers the configuration successfully.
----End
12.4.1.4 Configuring the Internet Access Service
The OLT is connected to the remote ONU through a GPON port to provide users with high-
speed Internet access services.
Prerequisite
l The OLT is connected to the BRAS.
l Related configurations are performed on the BRAS according to the authentication and
accounting requirements for dialup users. For details about the configuration, see the
configuration guide.
l The ONU has been added to the OLT. For details, see 12.4.1.3 Adding an ONU to an
OLT .
Data Plan
Table 12-19 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID for Internet access service: 14
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
Network topology data Upstream port: 0/19/0
PON port: 0/1/0
ONU IDs: 1 and 2
ID of the port on the ONU that is connected to the PC: 1
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1150
