Applicatio
n Scenario
Service
Type
VLAN Plan VLAN Translation Policy
Gateway
ONU
Multicast
service
Single-
tagged
VLAN
ONUs replicate packets based on user ports and
M-VLANs are removed in downstream
direction.
The OLT replicates multicast packets based on
PON ports with M-VLAN unchanged.
VoD Single-
tagged
VLAN
ONUs add C-VLAN tags to packets. Untagged
VLANs are translated to C-VLANs.
The OLT implements VLAN translation: C ->
S.
Note:
l UserVLAN: VLAN carried by upstream packets of user-side devices, U for short.
l C-VLAN: VLAN added based on the ONU port. For details, see the description of the
Double-tagged VLAN S+C.
l Double-tagged VLAN S+C: C indicates the inner VLAN (C-VLAN) and S indicates the
outer VLAN (S-VLAN).
l Double-layer VLAN S+C': C' indicates the translated inner VLAN (C'-VLAN) and S
indicates the outer VLAN (SVLAN).
l Single-tagged S-VLAN: Single-tagged VLAN marked or translated by the OLT. It is
generally used in a single-tagged VLAN translation scenario.
l C<->S+C': Bidirectional VLAN translation: translates the inner C-VLAN and then adds
one outer S-VLAN.
l C<->S+C: Bidirectional VLAN translation: maintains the inner C-VLAN and adds one
outer S-VLAN.
NOTE
l IPTV service is a closed service self-operated by carriers, and single-tagged S-VLAN is recommended.
l The same S-VLAN or different S-VLANs can be used as the M-VLAN and VoD VLAN. It is recommended
that you use different S-VLANs as M-VLAN and VoD VLAN so that the upper-level device easily
differentiates between the BTV service and VoD service.
l S-VLANs of VoD service can identify services and physical locations based on an entire network or an
OLT. It is recommended that you set different VoIP VLANs for the OLTs connected to one VoIP SR to
avoid an excessively large broadcast domain of the VoIP SR and convergence switch.
12.2.6 Principle of Security Data Plan
The security plan involves system security plan, user security plan, and service security plan.
Security policy ensures service security from different aspects.
