NOTE
To bind a LAN port to a WAN port, set Physical Port Name and WAN Interface
Name. The preceding figure shows that WAN 1 is bound to LAN 1.
To bind a WAN port to multiple LAN ports, set Physical Port Name to
LAN1,...,LANx. For example, to bind WAN 1 to LAN 1 and LAN 2, set Physical
Port Name to LAN1, LAN2.
3) Click OK.
2. Bind a general VAS profile.
a. In the Main Topology, double-click the required OLT in the Physical Root
navigation tree; or right-click the required OLT and choose NE Explorer from
the shortcut menu.
b. Choose GPON > GPON Management from the navigation tree.
c. In the window on the right, choose GPON ONU.
d. On the GPON ONU tab page, set the filter criteria or click
to display the
GPON ONUs.
e. Select an ONT from the list, right-click, and choose Bind General VAS
Profile from the shortcut menu. In the dialog box that is displayed, select the
created profile, and click OK to complete profile binding.
3. Configure the ONT value-added service.
a. On the GPON ONU tab page, select an ONT, right-click, and choose Configure
Value-Added Service from the shortcut menu.
b. Click the Basic Parameters tab in the dialog box that is displayed, select WAN
Port, set User Name to iadtest@pppoe, and set Password to iadtest. The user
name and password must be the same as those configured on the BRAS.
c. Click OK. The configurations take effect without the requirement of resetting
the ONT.
----End
9.7.3.5 Configuring the H.248-based Voice Service (on a Web Page or the U2000)
The OLT is connected to the remote ONT through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
669
