7. Check the ONU connection status.
In the navigation tree, choose Status > WAN Information. In the right pane,
Status is Connected and the obtained IP address is displayed at IP Address.
8. Check the registration status of the voice user.
In the navigation tree, choose Status > VoIP Information. In the right pane, User
Status is Up.
----End
10.6.1.10 Configuring the BTV Service
The OLT is connected to the remote bridging ONU through a GPON port to provide users with
the multicast service.
Prerequisites
l The OLT is connected to the BRAS and the multicast source.
l The VLAN of the LAN switch port connected to the OLT is the same as the upstream
VLAN of the OLT.
l The ONU has been added to the OLT. For details, see 10.6.1.3 Adding an ONU to an
OLT.
l A VDSL2 port has been activated. For details, see 10.6.1.4 Configuring a VDSL2 User
Port.
Data Plan
Table 10-4 Data plan
Item Data
ONU line profile Profile name: fttd
T-CONT ID: 4
GEM port ID: 13
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
775
