In this example, the default POTS port profile, namely POTS port profile 1 is used.
4. Bind a digitmap profile.
Run the sippstnuser digitmap command to bind a digitmap profile to an SIP interface, or
run the ont-sippstnuser bat-bind from command to bulk apply the digitmap profiles to
SIP interfaces. If you use these two commands to bind the SIP service data profiles to SIP
ports repeatedly, the last configurations take effect.
In this example, the default digitmap profile, namely digitmap profile 1 is used.
Step 6 (Optional) Configure the SIP user codec.
Run the sippstnuser codec command to configure the SIP user codec. The SIP user codec will
not be configured independently in this example.
Step 7 Save the data.
huawei(config)#save
----End
12.4.1.9 Configuring the BTV Service
The OLT is connected to the remote bridging ONU through a GPON port to provide users with
the multicast service.
Prerequisites
l The IPTV WAN ports on the ONU use factory defaults.
l The OLT has been connected to the BRAS and the multicast source.
l The ONU has been added to the OLT. For details, see 12.3.3 Adding an ONU to an
OLT.
Data Plan
Table 12-29 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 13
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1174
