No. Step Description
3 Add a remote extended frame to
the OLT.
An MA5633 that works as a remote extended
frame connects to a port on a cascading
board of an optical line terminal (OLT). You
can configure the remote extended frame
only after adding it to the OLT.
4 Configure radio frequency (RF)
port parameters.
Radio frequency (RF) port parameters
define the frequency spectrum range for
signal transmission and modulation mode.
The configuration of RF port parameters
implements data service transmission over
cables.
RF port parameters can be configured using
either of the following methods:
l Use a cable initialization profile to
configure the parameters.
l Customize the parameters in cable mode.
5
Configure the L2VPN service. In the upstream direction, a cable modem
(CM) connects to a distributed cable modem
termination system (D-CMTS) through a
cable. In the downstream direction, the CM
connects to a switch to provide the L2VPN
enterprise service to the users connected to
the switch.
6 Verify the configured service. An OLT supports multiple remote service
verification methods. This allows
commissioning and configuration engineers
to remotely verify services.
1. A DHCP dialup emulation test checks
whether the OLT can communicate with
the DHCP server and verifies CM DHCP
configurations on the DHCP relay,
proxy, and server.
2. The status of a CM can be queried. Based
on the information, you can determine
whether the CM is online.
15.3.2.3 Configuring DHCP Relay
This section describes how to configure Dynamic Host Configuration Protocol (DHCP) relay
so that cable modems (CMs) can obtain IP addresses in different network segments.
