Run the mgpstnuser codec command to configure the H.248 user codec. The H.248 user codec
will not be configured independently in this example.
Step 11 Save the data.
huawei(config)#save
----End
9.7.3.7 Configuring the SIP-based Voice Service (on a Web Page or the U2000)
The OLT is connected to the remote ONT through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
Prerequisites
l The SIP interface data and POTS user configuration data corresponding to the MG interface
have been configured on the SIP server.
l The connection between the OLT and the SIP server is set up. The OLT can ping the IP
address of the SIP server successfully.
l The ONT has been added to the OLT. For details, see 9.7.1.3 Adding an ONT to an
OLT.
l Different voice services require different ONT software versions. Before the configuration,
ensure that the current ONT software version supports SIP. For details, see relevant ONT
manuals.
Data Plan
Item Data
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 12
VLAN Plan Single VLAN tag:
l SVLAN ID: 200
l SVLAN type: smart
l SVLAN attribute: common
l CVLAN ID: 300
VLAN translation policy:
l ONT: VLANs are configured for the ONTs on the
same network in a unified manner, and the ONTs
have the same C-VLAN. The ONT adds a C-VLAN
tag to packets.
l OLT: translates the VLAN tag (C-VLAN <-> S-
VLAN).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
683
