NOTICE
Each ISDN BRA user occupies two TIDs. You need to input only the first TID when adding an
ISDN BRA user.
l When the TID profile to which the ISDN BRA user of the MG interface is bound is not a
layering profile, the TID must be configured and must differ from the TID of the existing
ISDN BRA user by an integer multiple of 2.
l When the TID profile to which the ISDN BRA user of the MG interface is bound is a layering
profile, the configuration of the TID is optional because the system automatically allocates
the TID.
Step 4 Save the data.
huawei(config)#save
----End
Result
After the configuration is completed, two ISDN BRA users of ports 0/2/0 and 0/3/0 can call each
other successfully.
Configuration File
board add 0/2 H802DSRD
board add 0/3 H802DSRD
board confirm 0/2
board confirm 0/3
braport
braport attribute set 0/2/0 workmode p2p activemode stable-active autodeactive
disable
braport attribute set 0/3/0 workmode p2p activemode stable-active autodeactive
disable
quit
sigtran
iua-linkset add 1 mgid 0 jointly-work enable trafficmode override
iid-map 2 pendingtime cs-mode client
iua-link add 15 1 1401 10.13.4.116 1400 10.14.1.2
jointly-work-with primary-mgc priority 3quit
esl user
mgbrauser add 0/2/0 0 1 interfaceid 8 terminalid 100 telno 12345601
mgbrauser add 0/3/0 0 1 interfaceid 9 terminalid 110 telno 12345602
quit
save
3.3.6 Example: Configuring the P2P ISDN BRA Service (Based on
the SIP Protocol)
This topic describes how to configure the P2P ISDN BRA service on the MA5600T/MA5603T/
MA5608T, which is applicable to the scenario where one NT1 is connected to only one terminal.
Service Requirements
l ISDN Phone A is connected to the MA5600T/MA5603T/MA5608T through the NT1, and
the ISDN digital phone supports the P2P function.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
332
