Create an Internet access service VLAN and add an upstream port to it. Add upstream
port 0/19/0 to VLAN 100.
huawei(config)#vlan 100 smart
huawei(config)#vlan attrib 100 stacking
huawei(config)#port vlan 100 0/19 0
Create Internet access service flows. Set S-VLAN ID to 100 and GEM port ID to 14.
Use traffic profile ftto_hsi.
huawei(config)#service-port vlan 100 gpon 0/1/0 ont 1 gemport 14 multi-
service
user-vlan 45 tag-transform translate-and-add inner-vlan 1001 inbound
traffic-table
name ftto_hsi outbound traffic-table name ftto_hsi
huawei(config)#service-port vlan 100 gpon 0/1/0 ont 2 gemport 14 multi-
service
user-vlan 45 tag-transform translate-and-add inner-vlan 1002 inbound
traffic-table
name ftto_hsi outbound traffic-table name ftto_hsi
3. Save the data.
huawei(config)#save
l The ONU does not need to be configured.
----End
12.4.1.5 Configuring the H.248-based Voice Service (on a Web Page)
The OLT is connected to the remote ONU through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
Prerequisite
l The interface data and POTS port data corresponding to the MG interface have been
configured on the MGC.
l The OLT has been connected to the MGC. The OLT can ping the IP address of the MGC
server successfully.
l The ONU has been added to the OLT. For details, see 12.3.3 Adding an ONU to an
OLT.
l Different voice services require different ONU software versions. Before the configuration,
ensure that the ONU software version supports H.248. For details, see relevant ONU
manuals.
Context
Table 12-21 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 12
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1152
