Run the pstnport electric command to apply a POTS port profile to an H.248 interface or
configure the interface customized parameters, or run the ont-pstnport electric bat-
apply command to bulk apply the POTS port profiles to H.248 interfaces. If you use these
two commands to apply the POTS port profiles or configure the interface customized
parameters repeatedly, the last configurations take effect.
In this example, the default POTS port profile, namely POTS port profile 1 is used.
Step 7 (Optional) Configure the H.248 user codec.
Run the mgpstnuser codec command to configure the H.248 user codec. The H.248 user codec
will not be configured independently in this example.
Step 8 Save the data.
huawei(config)#save
----End
12.4.2.7 Configuring the SIP-based Voice Service (on a Web Page)
The OLT is connected to the remote ONU through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
Prerequisite
l The SIP interface data and POTS port data corresponding to the MG interface have been
configured on the SIP server.
l The connection between the OLT and the SIP server is set up. The OLT can ping the IP
address of the SIP server successfully.
l The ONU has been added to the OLT. For details, see 9.7.1.3 Adding an ONT to an
OLT.
l Different voice services require different ONU software versions. Before the configuration,
ensure that the current ONU software version supports SIP. For details, see relevant ONU
manuals.
Data Plan
Table 12-41 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 12
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1209
