11.4.1.5 Configuring the Service Channel Between an OLT and an ONU
This section describes how to configure a service channel between an optical line terminal (OLT)
and an optical network unit (ONU). After the configuration, the service channel forwards service
packets on the ONU at Layer 2 based on the planned VLAN and forwarding policy.
Data Plan and Configuration Description
Planning the service channel between an OLT and an ONU is planning VLAN data. The
following table lists the data plan in various Ethernet cascading scenarios.
Networking Scenario Data Plan and Configuration Procedure
FTTB/FTTC Networking
(xDSL Access Without HGW)
Internet access service channel (Create a common S-VLAN
on the OLT to transparently transmit the Internet access
service packets from a stacking VLAN on the ONU. For
details about VLAN planning principles, see 11.2.3
Principle of Internet Access Service Data Plan):
l S-VLAN: 1001
l C-VLAN (Internet access service S-VLAN on the ONU):
1001
Voice service channel (The OLT transparently transmits
VLAN tags carried in voice service packets. For details
about VLAN planning principles, see 11.2.5 Principle of
VoIP Service Data Plan):
l S-VLAN: 200
l C-VLAN (Voice service S-VLAN on the ONU): 200
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1032
