Page #1343 background imageLoading...
Page #1343 background image
l Run the ping ONU ip command on the OLT to verify the connectivity between the OLT and
ONU. If the OLT receives ICMP ECHO-REPLY packets from the ONU, the connection is
reachable.
l When the connection is reachable, you can remote log in to the ONU from the OLT and
configure the ONU.
----End
13.3.4.5 Configuring Service Ports for Voice Transparent Transmission
This topic describes how to create service ports on the OLT to transparently transmit VoIP
service data from ONUs to the upper-layer voice server.
Data Plan
Configuration Item
Data
SVLAN VLAN ID: 300
VLAN attribute: common
CVLAN (upstream VALN of
the ONU)
300
Traffic profile Profile ID: 10
Assured bandwidth: 100 Mbit/s
Priority source: user-cos
Default priority: 5
NOTE
The VoIP service is a self-operated service. The single SVLAN is a mainstream application and is recommended.
Procedure
Step 1 Configure an SVLAN and add an upstream port to it.
Set the SVLAN ID of the PRA PBX service to 300, VLAN type to smart, and add upstream port
0/19/0 to the VLAN.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
Step 2 Configure a traffic profile for the service port.
Add a new traffic profile 10 and set the assured rate to 100 Mbit/s. Packets transmitted upstream
use the priority (5 by default) copied from the user side. Packets transmitted downstream use
the priority carried by themselves.
huawei(config)#traffic table ip index 10 cir 102400 priority user-cos 5 priority-
policy tag-in-package
Step 3 Configure a service port.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1318
