13.3.5.3 Adding ONUs to OLT
ONUs can be configured only after they are added to the OLT successfully.
Context
l When adding ONUs, you need to bind related profiles to the ONUs, including the DBA
profile, line profile, and alarm profile.
l An ONU can be added in two modes: offline addition and online confirmation. Select either
mode as required.
Data Plan
Table 13-10 Key data plan
Item Data
DBA profile Profile ID: 20
Profile type: Fixed bandwidth and minimum delay
DBA bandwidth:
l E1 access: 32 Mbit/s is recommended. (Each ONU accesses four E1
private lines and each line has a recommended DBA bandwidth of 8 Mbit/
s)
l T1 access: 24 Mbit/s is recommended. (Each ONU accesses four T1
private lines and each line has a recommended DBA bandwidth of 6 Mbit/
s)
Line profile Profile ID: 10
T-CONT ID: 1
GEM port ID for management service: 11
GEM port ID for DDN private line service: 12
Networking
data
PON port: 0/3/1
ONU parameters:
l ONU ID: 1
l SN: 32303131B39FD641
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile. and set the DBA bandwidth allocation mode for the GPON port
to minimum bandwidth delay.
For example, configure the DBA profile for 4-channel E1 private line.
huawei(config)#dba-profile add profile-id 20 type1 fix 32768
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#port dba bandwidth-assignment-mode 1 min-loop-delay
huawei(config-if-gpon-0/3)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1330
