Monitoring Solution Cabinet Type Typical Configuration
ETP4830 Monitoring
Solution
F01S300 One MA5603T shelf
ETP4890 Monitoring
Solution
F01D500 One MA5600T(MA5603T)
shelf
ETP48150 Monitoring
Solution
F01D2000 Two MA5600T(MA5603T)
shelves
Power3000 Monitoring
Solution
- Use this program when you
need to monitor the external
power supply Power 3000
Heat Exchanger Monitoring
Solution
- Heat Exchanger
Fan Tray Monitoring
Solution
- Fan Tray
1.3.16.2 Commissioning the EMU_ESC
This topic describes how to commission the H801ESC board to ensure that it monitors the
environmental conditions of the device according to the actual conditions.
Context
ESC stands for the environment and power monitoring board. The H801ESC board monitors
environment parameters such as temperature, humidity, smoke, water, fire, voltage, and power
supply through various sensors.
When commissioning the H801ESC board, pay attention to the following points:
l The EMU sub-nodes are numbered from 0 to 31.
l When the system is configured with multiple EMUs simultaneously, make sure that the
sub-nodes do not conflict with each other.
Table 1-23 lists the default configuration of the H801ESC board.
Table 1-23 Default configuration of the H801ESC board
Parameter Default Value
Sub-node 15
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
84
