According to 13.2.2 Principle of VLAN Data Plan, VLANs of packets sent from the PRA PBX
are all translated to CLVAN 300. The OLT transparently transmits the packets. The traffic profile
10 is used.
huawei(config)#service-port vlan 300 gpon 0/3/1 ont 1 gemport 12 multi-service
user-vlan 300 rx-cttr 10 tx-cttr 10
----End
13.3.4.6 Configuring VoIP PRA Access
This topic describes how to configure VoIP PRA access. ONUs provide PRA E1 ports to access
the PRA PBX service and convert PRA signaling to ISDN Q.931-User Adaptation Layer (IUA)
signaling, achieving signaling exchange between ONUs and media gateway controller (MGCs).
Prerequisites
The H.248 protocol is a master/slave protocol which is used by an MGC to control access
gateways (AGs) to implement call connections. The data, including media gateway (MG)
interface attributes and voice user attributes on AGs, must be consistent with those on the MGC.
Therefore, before configuring the VoIP voice service, plan data with the MGC.
Context
IUA is the ISDN Q.931-User Adaptation Layer protocol. IUA links carry signaling exchanged
between ONUs and MGCs.
Data Plan
Table 13-8 Data plan for VoIP PRA service
Configuration
Item
Data
VLAN VLAN ID: 300
IP address of the Layer 3 interface: 10.10.10.10/24
MG interface MG ID: 0
Media/signaling IP address: 10.10.10.10/24
MGC IP address: 200.200.200.200
Gateway IP address: 10.10.10.1
Protocol port: 2944
IUA linkset IUA link set ID: 1
Working mode of the link set: override
Interface ID (IID) generation mode: 2
Service environment of the IUA link set: client
Interlocking function: enabled
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1319
