Scenario Description Typical OLT
Configuration
(Main Control
Board+Service
Board
+Upstream
Board)
Applicable ONU
Ethernet
base station
access service
(in QinQ
VLAN mode)
ONUs receive the ETH
service data from 3G base
stations through FE/GE ports,
encapsulate the ETH packets
into GEM frames, and then
send them to the OLT through
the GPON upstream ports.
The OLT restores the ETH
signals and configures QinQ
VLANs for the signals to
enable the data of base
stations to be transparently
transmitted to the remote
PTN over the public network.
Then the remote PTN device
restores the ETH signals.
SCUN+GPBC/
GPBD+GICK/
X2CS
MA5612, MA5628
14.1.3 GPON ONU Capability Set
This topic describes the supported hardware capability, features, and network position of ONUs
on a GPON FTTM access network.
In FTTx V100R013C00, the MA5694S, MA5698, MA5898, MA5612, MA5628 and MA5673
mainly apply to the FTTM access service. Table 14-1 shows the ONU capability set.
Table 14-1 ONU capability set
ONU
Type
User Interface Supported ONU
Version
MA5694S As an outdoor box-type device, MA5694S is used for
data backhaul of small cell base stations. It provides the
following interfaces:
l 1*GE optical interface for Ethernet access
l 3*GE electrical interfaces for Ethernet access, power
on Ethernet is supported
l 1*GPON interface for upstream
V800R313C10
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1364
