NOTE
The interconnected router must set static routes and add the routes to dynamic routes.
----End
Result
The OLT can communicate with its upper-layer devices. To check network connectivity between
two devices, run the ping and tracert commands.
The configured static routes can be queried in an IPv4 routing table by running the display ip
routing-table command.
16.4.2.5 Configuring DHCP Relay (IPv6)
This section describes how to configure DHCPv6 relay so that CMs can obtain IP addresses in
different network segments.
Prerequisites
The upper-layer router, DHCP server, and Trivial File Transfer Protocol (TFTP) server of an
OLT have been configured.
Data Plan
Table 16-39 data plan
Configuration Item Data
Terminal-side of CM network segment of CM: 2001:0db8:0001::/64
User-side of OLT IP address of the gateway for the DHCP domain of CMs:
2001:0db8:0001::1/64; domain name: docsis
Network-side of OLT Forwarding DHCP and broadband packets:
l VLAN ID: 2004
l Port number: 0/4/0
l IP address: 2001:0db8:0007::12/64
Forwarding CM management packets, multicast packets, and
VoD packets:
l VLAN ID: 2005
l Port number: 0/5/0
l IP address: 2001:0db8:0008::13/64
Router
l IP address of the Layer 3 interface for forwarding DHCP and
broadband packets: 2001:0db8:0007::6/64
l IP address of the Layer 3 interface for forwarding CM
management packets: 2001:0db8:0008::7/64
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1774
