13.3.6.3 Configure OLT_A cascading with OLT_B
Prerequisites
Required hardware for OLT_A is ready.
l Control board: SCUN+CKMC/CKMD
l GPON service board: GPBD
l Upstream board: EDTB
l Cascaded service board:
– GE port: GICK or OPGD
– 10GE port: X2CS
Data Plan
Table 13-11 provides the key data plan.
Table 13-11 Key data plan for OLT_A
Item Data Remarks
OPGD Port: 0/2/1 Assume that OLT_A is cascaded with OLT_B using the
OPGD board. Then you need to set the network role of the
OPGD board to cascade.
VLA
N ID
and IP
addres
s
In-band management
VLAN ID: 8
In-band management
IP address:
192.168.50.30/24
To telnet to another OLT or ONU from the OLT and then
configure the OLT or ONU, you must configure the in-band
management VLANs and IP addresses of the OLT on the
OLT.
If the management IP address and the IP address of OLT_B
or ONU_B are not in the same network segment, you also
need to configure routes.
Procedure
Step 1 Configure the management VLAN and IP address.
Create management VLAN 8, and set the management IP address to 192.168.50.30 and subnet
mask to 255.255.255.0.
huawei(config)#vlan 8 smart
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.30 24
Step 2 Configure cascading with OLT_B.
Cascade OLT_A and OLT_B through GE port 0/2/1 on the OPGD board. Set the port attribute
to cascade, and add the cascading port to VLAN 300.
huawei(config)#interface opg 0/2
huawei(config-if-opg-0/2)#network-role cascade
huawei(config-if-opg-0/2)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1347
