huawei(config-mvlan1000)#igmp mode proxy
Are you sure to change IGMP mode? (y/n)[n]:y
Command is being executed. Please wait...
Command has been executed successfully
6. Configure the IGMP upstream port.
Set the IGMP upstream port ID to 0/19/0 and working mode to default. Protocol
packets are transmitted to all the IGMP upstream ports in the multicast VLAN.
huawei(config-mvlan1000)#igmp uplink-port 0/19/0
huawei(config-mvlan1000)#btv
huawei(config-btv)#igmp uplink-port-mode default
Are you sure to change the uplink port mode?(y/n)[n]:y
7. (Optional) Set multicast global parameters.
In this example, the default settings are used for all the multicast global parameters.
8. Configure multicast users.
Add service ports 1 and 2 as multicast users.
huawei(config-btv)#igmp user add service-port 1
huawei(config-btv)#igmp user add service-port 2
huawei(config-btv)#multicast-vlan 1000
huawei(config-mvlan1000)#igmp multicast-vlan member service-port 1
huawei(config-mvlan1000)#igmp multicast-vlan member service-port 2
huawei(config-mvlan1000)#quit
9. Save the data.
huawei(config)#save
l The ONU does not need to be configured.
----End
12.4.1.10 Configuring the VoD Service
The OLT is connected to the remote bridging ONU through a GPON port to provide users with
the VoD service.
Prerequisites
l The OLT is connected to the BRAS and the program source.
l The ONU has been added to the OLT. For details, see 12.3.3 Adding an ONU to an
OLT.
Data Plan
Table 12-31 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 13
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1177
