End
Configuring the IP Address of the
NMS Server and the IP Address
Pool of the ONU
OLT ONU
Creating the Authentication-Free
Policy and Associating It with the
OLT
Configuring the Remote
Software Commissioning Policy
U2000
14.4.9.3 Configuring the IP Address of the NMS Server and the IP Address Pool of
the ONU (GPON Dock Scenario)
Prerequisites
l The OLT is added to the NMS.
l Related xFTP configurations are completed.
Data Plan
Configurati
on Item
Data Remarks
IP address of
the NMS
server
10.10.10.10 The NMS server needs to use ports 23,
8080, 9801, and 9803. Therefore, ensure
that the firewall does not block these ports
so that the NMS server can normally
communicate with devices.
IP address of
the OLT
10.10.10.20 This IP address is designated for Layer 3
VLAN interface 8 and is used for inband
management.
IP address
pool of the
ONU
IP address pool: 10.10.11.2 to
10.10.11.125
Subnet mask: 255.255.254.0
ONU gateway: 10.10.10.20
Management VLAN ID: 8
VLAN priority: 7
The ONU gateway IP address is used as
the IP address of the Layer 3 interface on
the OLT.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1505
