Command is being executed. Please wait...
Multicast flow statistic result: 8736(kbps)
----End
9.7.4 Configuring Triple Play Service (Simplified Mode)
The GPON service configuration in simplified mode is implemented by creating an end-to-end
(E2E) service port between an OLT and an ONT. This topic describes how to achieve the GPON
service configuration in simplified mode by configuring the Internet access service, voice
service, and multicast service in the FTTH scenario.
Service Requirements
NOTE
On the same ONT, service ports in the simplified mode conflict with services ports in the profile mode. Therefore,
they cannot be configured concurrently.
l Subscribers use the bridging ONTs (supporting VoIP). The PC, STB, and phone are
connected to different ports on the ONT to achieve the triple play service.
l Different services are distinguished by different S-VLANs on an OLT.
l The internet access service has a rate restriction of 4 Mbit/s both in upstream and
downstream directions.
l IPTV service has no rate restriction in upstream or downstream direction.
l The VoIP adopts the H.248 protocol and the phones connected to different ONTs can
communicate with each other.
Figure 9-7 shows an example network of the FTTH triple play service.
Figure 9-7 Example network of the FTTH triple play service
Prerequisite
l The OLT is connected to the BRAS, MGC, and the multicast source.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
710
