huawei(config)#cable service-vlan 100
Info: The new service VLAN will take effect after the CM is restarted, are you
sure to modify? (y/n)[n]:y
----End
16.4.1.13 Configuring the EQAM VoD Service on an MA5633
If the MA5633 is equipped with a built-in EQAM module, the MA5633 sets idle downstream
DOCSIS channels as EQAM channels to transmit VoD data.
Prerequisites
The MA5633 supports built-in EQAM.
Context
In multiservice operator (MSO)-oriented solutions, both HFC networks and STBs use the
broadcast television QAM technology and support only RF signals.
Video data is encapsulated into IP and UDP packet headers that are transmitted on IP networks,
which cannot be transmitted on HFC networks. To transmit the video data on HFC networks,
the video data must be modulated into RF signals using the EQAM module.
Video data transmission on HFC networks uses existing CATV coaxial cables on the HFC
networks, thereby reducing network deployment costs.
Data Plan
Table 16-33 Data plan for the VoD service
Item Data
EQAM IP address 10.10.10.10
VLAN ID of the VoD S-VLAN: 50; type of the VLAN: smart
Uplink port Forwarding CM management, VoD, and multicast packets: 0/0/1
EQAM channel ID 13-16
Modulation mode QAM 64
Symbol rate 6.875
UDP port number 501-514
Access port on the OLT 0/3/0
Uplink port on the OLT 0/5/0
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1757
