Plan Device/Service Description
IPTV service As a DHCP client, the ONU obtains a public
network IP address through DHCP. As a DHCP
server, the ONU allocates private IP addresses to
STBs. After NAT, all the STBs connected to the
ONU use a public IP address to order programs.
VoIP service As a DHCP client, the ONU obtains a public IP
address through DHCP, or the NMS allocates an IP
address to the ONU through a configuration file, or
the ACS allocates a static IP address to the ONU
through TR069. The voice signaling streams and the
media streams of multiple POTS ports share the IP
address. Media streams can be distinguished by
different ports.
TR069
management
In TR069-based management, maintenance and
service provisioning, the ONU, functioning as a
DHCP client, obtains a public network IP address
through DHCP and connects to the TR069 server
(ACS).
12.2.2 Principle of QoS Planning
The QoS planning is an E2E planning, and it can be divided into following policies: traffic
classification, marking, and scheduling policy; and traffic monitoring and DBA policy.
Traffic Classification, Marking, and Scheduling Policy
Service
Type
802.1p
Priority
Queue
Scheduling
Method
OLT
Queue ID
(8 Queues)
ONU Queue.ID
When
Eight
Queues
Are
Supported
When Four
Queues
Are
Supported
Management
service
6 PQ 6 6 3
VoIP service 5 PQ 5 5 2
IPTV service 4 PQ 4 4 2
Internet
access
service
0 PQ 0 0 0
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1082
