l If Control flag is deactive, run the ont active command in GPON mode to activate the
ONU.
l If Run state is offline, a physical line may be broken or the optical module may be damaged.
Check the line and the optical module.
l If Config state is failed, the configured ONU capability exceeds the actual ONU capability.
In this case, run the display ont failed-configuration command in the diagnose mode to
check the failed configuration item and the failure cause. Then, rectify the fault accordingly.
l If the ONU does not match, that is, Match state is mismatch, the port types and number
of ports undermatch the actual port types and number of ports supported by the ONU. In
this case, run the display ont capability command to query the actual capability of the
ONU, and then select one of the following modes to modify the ONU configuration:
– Create a proper ONU profile according to the actual capability of the ONU, and then
run the ont modify command to modify the configuration data of the ONU.
– Modify the ONU profile according to the actual capability of the ONU and save the
modification. Then, the ONU automatically recovers the configuration successfully.
11.3.2.4 Configuring the Management Channel Between the OLT and the ONU
After the inband management channel between the OLT and the ONU is configured and
available, you can log in to the ONU from the OLT to configure the ONU.
Data plan
Item Data Remarks
Management VLAN
and management IP
address on the OLT
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.1/24
To configure the MDU from the OLT
by remote logging in to the MDU, the
management VLAN of the OLT and
that of the MDU must be the same, and
the management IP address of the OLT
and that of the MDU must be in the
same network segment.
Management VLAN
and management IP
address on the ONU
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.2/24
Procedure
Step 1 Configure the inband management VLAN and IP address of the OLT.
Configure the inband management VLAN to 8, VLAN priority to 6, and the IP address to
192.168.50.1/24.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/19 0
huawei(config)#vlan priority 8 6
huawei(config)#interface vlanif 8
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
888
