l Multicast program priorities: 254 and 255
huawei(config)#cable multicast authorization enable max-sessions 32 default-acti
on permit
huawei(config)#cable multicast auth-profile profile-name btv1
huawei(config-multicast-profile-btv1)#rule 1 priority 255 group-ip 225.1.1.1 gro
up-ip-mask 24 src-ip 192.168.20.11 src-ip-mask 24 permit
huawei(config-multicast-profile-btv1)#rule 1 priority 254 group-ip 225.1.1.2 gro
up-ip-mask 24 src-ip 192.168.20.11 src-ip-mask 24 permit
Step 11 (Optional) Configure cable multicast version.
huawei(config)#cable multicast igmp-version v3
----End
15.3.1.13 Configuring the Dynamic PacketCable Service
A cable modem (CM) connects to a distributed cable modem termination system (D-CMTS)
through a cable and provides the dynamic PacketCable service for users.
Context
Table 15-18 Data plan for the PacketCable service on the OLT
Item Data
Uplink port Forwarding VoIP packets: 0/4/0
VLAN ID of service VLAN: 100
ID of the common open policy service (COPS) connection VLAN: 1000
IP address for
creating a COPS
connection to an IP
multimedia
subsystem (IMS)
or a softswitch
192.168.60.3/24 (in the same network segment as the IMS or softswitch
or can communicate with the IMS or softswitch)
Procedure
Step 1 Create a service VLAN (S-VLAN).
NOTE
All home services use an S-VLAN and the S-VLAN is globally configured. If the S-VLAN has been configured
for other home services, use the S-VLAN in steps Step 1 and Step 2.
The ID of S-VLAN is 100 and the type of the VLAN is smart. The S-VLAN is a user-side service
VLAN between the OLT and the D-CMTS. The OLT works in Layer 3 forwarding mode.
huawei(config)#vlan 100 smart
Step 2 Create a CM S-VLAN.
The CM S-VLAN identifies a CM service flow. After the CM S-VLAN is configured, the OLT
automatically creates a CM service flow when the CM goes online.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1563
